Navrženo pro ochranu panelu proti nárazům a vandalismu pro venkovní použití.
Testováno dle P2A
webOS Smart Platforma
Čtyřjádrový SoC (System-on-Chip) může vykonávat několik úloh současně bez potřeby samostatného mediálního přehrávače. Platforma webOS 3.0 navíc zvyšuje komfort uživatele pomocí intuitivního uživatelského rozhraní a jednoduchých nástrojů pro vývoj aplikací.
Webové monitorování
LG Control Manager*, vestavěný webový monitorovací program, umožňuje diagnostikovat v reálném čase různé parametry jako teplotu, okolní světlo a gyrosenzory. Lze jej snadno ovládat kdykoliv.
Aktivováno připojením přes kabelové LAN
Volitelný stojan
Volitelný stojan umožňuje, aby panel volně stál, a usnadňuje správu kabeláže.
| Tech Spec | |
Panel | |
Screen Size | 75" Class (74.52 inch Measured Diagonal) |
| Panel Technology | IPS |
| Back Light Type | Direct |
| Aspect Ratio | 16:09 |
| Native Resolution | 3,840 × 2,160 (UHD), M+ |
| Pixels (H x V x 3) | M+ (RGBW) |
| Refresh Rate | 60Hz |
| Brightness | 3,000 cd/m2 (Typ.), 2,400 cd/m2 (Min.) through Front Protective Glass |
| Contrast Ratio | 1,200 : 1 |
| Dynamic CR | 500,000 : 1 |
| Color gamut | 72% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 1.07 Billon (10 bit) |
| Response Time | 8 ms (G to G BW) (Typ.) |
| Surface Treatment | AGLR (Haze 3%), QWP |
| Lifetime | 50,000 Hrs |
| Operation Hours | 24 Hrs |
| Orientation | Portrait only |
| QWP (Quarter Wave Plate) | Yes |
Physical Specification | |
Front glass | 9.5 mm (AR, Front Safety Vandal Glass) |
| Color | Medium Texture Black (Common Color) |
| Bezel Width | 110 mm (Top), 230 mm (Bottom), 73.3 mm (Left/Right) |
| Monitor Dimension (W x H x D) | 1,075.6 × 1,991.6 × 218.9 mm |
| Weight (Head) | 180 kg |
| Monitor with Optional Stand Dimensions (W x H x D) | 1,075.6 × 2,361.6 × 218.9 mm |
| Weight (Head+Stand) | 247 kg |
| Packing Dimensions (W x H x D) | 1,292 × 2,296 × 468 mm |
| Packed Weight | 210 kg |
| Handle | Option (EYE-Bolt Ready) |
Environment Conditions | |
Operation Temperature | -30°C to 50°C |
| Operation Humidity | 5% to 100% |
| Direct Sunlight | Yes |
| Dust / Water Proofing | IP56 |
Power | |
Power Supply | 100-240 V ~, 50/60 Hz |
| Power Type | Built-in Power |
Power Consumption | |
Typ. | 750W (Full White) |
| 403W (IEC 62087) | |
| Max. | 1,000 W |
| DPM | 1 W |
| Power off | 0.5W |
Certification | |
Safety | UL / cUL / CB |
| EMC | FCC Class "A" / CE / KC |
| ErP / Energy Star | No / No |
Media Player Compatibility | |
External Media player Attachable | Yes (Available for Media Player Installation Inside Enclosure) |
Software Compatibility | |
| SuperSign (CMS (CMS 2.5), Control (Link 1.5)) | |
Connectivity | |
Input | Digital (With HDCP) (HDMI (HDCP 2.2, Available to Connect a Cable through a Hole at the Bottom, or Built-in Media Player), DP (HDCP 1.3, In Case of Built-in Media Player), DVI-D (In Case of Built-in Media Player)), Audio (In Case of Built-in Media Player), External Control (RS-232C (In Case of Built-in Media Player), RJ45), USB 3.0 (Available to Connect a Cable through a Hole at the Bottom, or Built-in Media Player), SD Card (SDHC/Full Size), HDTV Formats (HDMI : 720p, 1080i, 1080p) |
| Output | Digital (With HDCP) (DP (In Case of Enclosure Video Wall (e.g. QSR 1 × 3))), External Speaker Out (L/R), External Control (RS-232C (in Case of Enclosure Video Wall (e.g. QSR 1 × 3))) |
Language | |
OSD / USB Playback | English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues (Europe), Dutch, Czech, Greek, Arabic |
| Manual | Manual Language : English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Ukrainian, Polish, Arabic, Indonesian, Korean, Turkish, Czech, Slovak, Taiwanese, Danish, Norwegian, Swedish, Finnish, Uzbekistan |
| ESG | English, French, Italian, German, Spanish, Portugues, Greek, Polish, Czech, Slovak |
| Control Manager | English |
Accessory | |
| Remote Controller, Manual, QSG, Regulation Book, Phone to RS-232C Gender, USB Cable, HDMI Cable, Optional Accessory (Enclosure Stand (ST-750X)) | |
Special Feature | |
| Temperature Sensor (Main, Panel, LCM, PSU), Auto Brightness Sensor, Pixel Sensor (Built-in Pixel Sensor), Cooling FAN (Closed Loop FAN/Open Loop FAN), Tile Mode, Natural Mode, Source Selection (HDMI, DP, DVI, USB, SD Card), Brightness/Contrast/Backlight, ISM Method (Normal, White Wash, Color Wash, User Image, User Video, Orbiter, Inversion, Washing Bar), Advanced (Dynamic Contrast, Dynamic Color, Color Gamut, Skin Color, Sky Color, Grass Color, Gamma), Time (Clock, On/Off Time, Auto Off, Automatic Standby), Information (Model/Type, Software Version, Serial Number, IP Address, Homepage), Input Label (PC/DTV), Power on Status (Standby, PWR, LST), Key Operation (IR Operation), DPM Select, DPM Wake Up (Digital : Clock/Clock + Data Selectable), Energy Saving (Auto, Minimum, Medium, Maximum, Screen Off), Smart Energy Saving, Power Indicator On/Off, File Play with USB, Internal Memory 8 GB (System 4 GB + Available 4 GB), USB Cloning (Logo Image Download, Sent to USB, Receive From USB), Contents Scheduling (USB, Internal Memory, SD Card), Daylight Saving Time (Summer Time), Sync Mode (Time Sync, Content Sync), PM Mode (Power Off, Sustain Aspect Ratio, Screen Off, Screen Off Always, Screen Off & Backlight (Outdoor)), Holiday Schedule, Firmware Update (LAN), Local Time Auto Setting, Still Image Diagnosis, HDMI-CEC, Limited Mode (OSD, Settings Locking) (USB, IR, OSD), Wake on LAN, Digital Audio Input, Power on Delay (0-250), Content Rotation (0,90.180,270), OSD Portrait Mode (0,90.180,270), Password Change, Set ID Setup (Manual, Auto), Configuration Setup (USB Auto Playback), Lock Mode (USB, OSD, IR Operation), Fail Over (USB, SD Card, DP, DVI, HDMI, Internal Memory), SuperSign Server Setup (Signage Name, Server IP Setting, Server IP Status), Check Screen (via Pixel Sensor), DP Daisy Chain (DP, HDMI, DVI) | |
VIDEO (PC) | |
Max Input Resolution | 3,840 × 2,160 @ 60 Hz (HDMI, Display Port) |
| Recommended Resolution | 3,840 × 2,160 @ 60 Hz (HDMI, Display Port), 1,920 × 1,080 @ 60 Hz (DVI) |
| H-Scanning Frequency | 30-135 kHz |
| V-Scanning Frequency | 30-60.31 Hz |
| Pixel Frequency | HDMI-DTV : 594 MHz, HDMI-PC : 297 MHz |
| Sync Compatability | Digital |
| Video Input | HDMI, DVI-D, Display Port |
| Picture mode | Vivid, Standard, APS, Cinema, Sports, Game |
| Color temperature | Warm50 ~ Cool50 |
Audio | |
| Balance, Audio Power (20 W (10 W × 2)), Speaker On/Off, Clear Voice II, Virtual Surround Plus, Equalizer, Sound Mode (Standard, News, Music, Cinema, Sports, Game) |
