| Tech Spec | |
Panel | |
Screen Size | 86" |
| Panel Technology | IPS |
| Back Light Type | Direct |
| Aspect Ratio | 16:09 |
| Native Resolution | 3,840 X 2,160 (4K UHD) |
| Refresh Rate | 60 Hz |
| Brightness | 400 nit (w/o Glass Typ.) |
| Contrast Ratio | 4,000 : 1 |
| Dynamic CR | 5,000 : 1 |
| Color gamut | NTSC 72% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 10 bit (8 bit + FRC) |
| Response Time | 6.5 ms (Typ.) |
| Surface Treatment (Haze) | 25% |
| Lifetime | 50,000 Hrs (Min.) |
| Operation Hours (Hours / Days) | 16.VII |
| Portrait / Landscape | No / Yes |
Mechanical | |
| Specification | |
Bezel Color | Black |
| Bezel Width (T / R / L / B) | 34.3 / 15.6 / 15.6 / 37 mm |
| Weight (Head) | 63.5 kg |
| Packed Weight | 80.1 kg |
| Monitor Dimensions (W × H × D) | 1,957 × 1,171 × 86 mm |
| Carton Dimensions (W × H × D) (Box Outer Size) | 2,110 × 1,291 × 225 mm |
| Handle | Yes (2) |
| VESA™ Standard Mount Interface | 800 × 600 |
| Protection Glass (Degree of Protection) | Safety Glass |
| Protection Glass (Thickness) | 3.2 mm |
| Protection Glass (Tempered / Chemical Strengthening) | Tempered Strengthening |
Feature | |
Key Feature | Internal Memory (64 GB), Built-In Wi-Fi (Slot Type), Temperature Sensor, Auto Brightness Sensor, Power Indicator, Built-in MIC (8), webOS ver. (Android 13 (EDLA)), Booting Logo Image, PIP (External Source), Screen Share (LG CreateBoard Share), Smart Energy Saving (Energy Saving), Wake on LAN, Network Ready (Fast Power On), HDMI-CEC |
Environment Conditions | |
Operation Temperature | 0°C to 40°C |
| Operation Humidity | 10% to 90% |
Power | |
Power Supply | 100-240 V ~, 50/60 Hz |
| Power Type | Built-In Power |
Power Consumption | |
Typ./Max. | 280 / 530 W |
| Smart Energy Saving (70%) | TBD |
| DPM | 0.5 Wˇ |
| Power off | 0.5 Wˇ |
| BTU (British Thermal Unit) | 1,280 BTU/Hr (Typ.), 1,945 BTU/Hr (Max.) |
Certification | |
Safety | IEC62368, EN62368, GB4943, UL62368 |
| EMC | FCC Class "A" |
| ErP / Energy Star | Yes / Yes |
OPS Compatibility | |
OPS Type Compatible | Yes |
| OPS Power Built In | Yes |
Software Compatibility | |
LG ConnectedCare | Yes |
Connectivity | |
Input | HDMI (4, HDCP 2.3), DP (1, HDCP 1.3 / 2.3), Audio In, RS-232C In, RJ45 (LAN), USB (2, Type C), USB 3.0 (4, Type A), USB 2.0 (3, Type A) |
| Output | HDMI Out, Audio Out, Touch USB 2.0 (2, Type A), RJ45 (LAN) |
Sound | |
Speaker | Yes (18 W × 2, 8 W × 2) |
Language | |
| English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Portugues (Europe), Dutch, Czech, Greek, Arabic, Polski, Hungary, Romania, Thai, Turkiye, Ukraine, Basque, Catalan, Kazakhstan, Indonesia |
Accessory | |
Basic | Power Cord (3 M × 1), USB Cable (Type A-Type B) 5 M × 1, USB Type-C Cable (C to C) 1.8 M × 1, HDMI Cable (3 M × 1), Writing Pen × 2 Pcs, User Manual, QSG, Carton Box, Remote Controller, Wi-Fi Module |
| Optional | Wall Mount (WM-L000S), Floor Stand (ST-000F / ST-860F) |
Touch | |
Available Object Size for Touch | O2 mm^ |
| Writing Height | ?1 mm |
| Response Time | ?2.5 ms |
| Accuracy | ±1 mm (Typ.) |
| Interface | USB 2.0 |
| Protection Glass Thickness | 3.2 mm |
| Protection Glass Transmission | 88% |
| Operating System Support | Windows 10 / 8 / 7 / Android |
| Multi Touch Point | 50 Points (Max.) |
Android System | |
CPU | Octa-core A76 × 4 + A55 × 4 |
| GPU | Mali G52MP2 |
| RAM | 8 GB |
| Storage | 64 GB |
| Wi-Fi | 802.11 a/b/g/n/ac/ax |
| LAN | Gigabit LAN |
| Bluetooth | Bluetooth 5.0 |
| OS ver. | Android 13 (EDLA) |
